IW-RS436-07

4U NVMe Hybrid Storage Server

.Intel® Xeon Scalable & AMD EPYC family compliant
.Backplanes with Mini-SAS HD, OCuLink, or Slimline connectors (compatible with PCIe 4.0)
.End-to-end 12Gbps SAS host, expander, and disk support
.2.5"/3.5" HDD trays x 36 (optional NVMe trays x 12, distinguishes U.2 NVMe SSDs)
.2 x 2.5" SAS/SATA SSDs for system disks at the rear of the chassis
.Highly efficient 1200W, 80 Plus® Platinum CRPS (optional)
.High-speed cooling fans for excellent thermal performance
.4U High-density drawer configuration design for space-saving

NVME Storage Server for Mixed-Use Workloads

The IW-RS436-07 is a hybrid storage server performance gains from cost-effective SAS/SATA hard drive disks and high-speed/performance NVMe storages. It is designed for large amounts of data, real-time analytics, high-speed data streaming, and mainstream enterprise environments. The "mixed-use" workload drives make it ideal for running a wide range of customer applications.

Intel® Xeon Scalable family
2.5"/3.5" HDD
AMD EPYC family
x12 bays
System disks
CRPS
80 x 38mm fans x 8
26" deep chassis
28" slider rails

Guaranteed Data Efficiency

The RS436-07 supports 2.5"/3.5" hot-swap HDD trays x 36 (optional U.2 NVMe trays x 12) and delivers the most usable effective storage capacity and meets the capacity expansion requirements of data-intensive workloads and quick read/write operations.

Front View
Rear View

Hot-Swappable Capabilities

The 2.5"(15mm) U.2 form factor design works seamlessly with our latest generation backplanes. Hot-swap and tool-free design allow users to mount/remove 3.5" HDDs quickly and easily without any screws.

Users can also mount 2.5" SSDs with screws if needed.



Distinguishable Storage Functions

Multi-color HDD tray options cater to the different hard drive functions and distinguishes them from each other.

SAS/SATA/NVMe



Distinguishable Storage Functions

Multi-color HDD tray options cater to the different hard drive functions and distinguishes them from each other.

SAS/SATA/NVMe



Distinguishable Storage Functions

Multi-color HDD tray options cater to the different hard drive functions and distinguishes them from each other.

SAS/SATA/NVMe



Mini-SAS HD & Slimline or OCuLink Backplane

InWin’s exclusive backplane comes with great connectivity and is designed to support SAS/SATA and NVMe for Slimline or OCuLink host interface. The onboard expander mainly manages the communication of SAS/SATA HDD interface, it integrates end-to-end connectivity and reduces cable clutter.

Thermal Efficiency

Meets the thermal target for Intel® Xeon Scalable processors & AMD EPYC family, the IW-RS436-07 comes with 80 x 38mm PWM hot-swap fans x 8, featuring anti-vibration and produces low noise volume, but presents a strong current to have optimal heat dissipation.

80 Plus® Platinum CRPS

Options include 80 Plus® Platinum Certified CRPS with 1200W/1600W variants, which stabilizes the operation of the system, and greatly enhances the system’s availability.

CRPS Cable Information


24-pin Main Motherboard

8 pin CPU

12V 8pin front BP

12V 8pin front BP

12V 8pin rear BP

8 pin CPU

5V 6pin front BP

5V 6pin front BP

5V 6pin rear BP

4-pin rear 2.5"
HDD BP

PMBus

Tool-less Features

Tool-less items such as ball-bearing slide rails, top cover button, hot-swap trays, and fan modules offered by InWin assist users with a simplified building process.

Ball-bearing slide rails

Top cover open button

3.5" to 2.5" HDD tray

Hot-swap fan modules

Dimensions

Specification
Industry Standard EIA-RS310D
M/B Form Factor ATX(12" x 9.6"), CEB(12" x 10.5"), EEB(12" x 13")
Drive Bay • External 2.5"/3.5" hot-swap trays x 36 (optional U.2 NVMe SSD tray x 12)
• Rear 2.5" screwless hot-swap SSD trays x 2 (supports SAS 12Gbps)
Power Supply Supports:
• Form factor: 80 Plus Platinum CRPS
• Watt: 1200W
Indicator Power LED, LAN1/LAN2/LAN3/LAN4 LED, system LED, ID LED, HDD LED
Front Control Panel Power on/off, reset, NMI, ID SW, USB3.0x2
Backplane Type-1 • Front host: Mini-SAS HD (SFF-8643) x 3, Slimline (SFF-8654) x 8
• Front HDD: SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8
• Rear Host: Mini-SAS HD (SFF-8643) x 3, Slimline (SFF-8654) x 4
• Rear HDD: SAS/SATA x 12 or SAS/SATA x 8 and NVMe SSD x 4
Backplane Type-2 • Front Host: Mini-SAS HD (SFF-8643) x 3, OCuLink (SFF-8611) x 8
• Front HDD: SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8
• Rear Host: Mini-SAS HD (SFF-8643) x 3, OCuLink (SFF-8611) x 4
• Rear HDD: SAS/SATA x 12 or SAS/SATA x 8 and NVMe SSD x 4
12Gbps Expander Module Broadcom SAS 35 x 36R expander
Cooling Fan 80 x 38mm PWM hot-swap top fans x 4, 8300RPM
80 x 38mm PWM hot-swap bottom fans x 4, 12000RPM
Modular design with anti-vibration
Expansion Slot Low-profile PCI slots x 7
Material • Material: SGCC
• Thickness: 1.2mm
Rail Kit Supports 28" ball-bearing slide rail
Product Dimensions (DxWxH; Chassis Only) 659.3 x 448.5 x 174.5mm
(26" x 17.7" x 6.9")
Package Dimensions (DxWxH) 920 x 610 x 315mm
Weight (Chassis Only) • Net weight: 26.56kg
• Gross weight: 30.51kg
Cubic Feet 6.24
Container Information Single packing with pallets:
• 20': 120pcs
• 40': 252pcs
• 40'HQ: 294pcs

12Gbps Backplane Specifications

Front Backplane Type-1 Mini-SAS HD & Slimline front backplane
Dimension (W x H) 386 x 162mm
Backplane Type Active with expander onboard
Host Interface Mini-SAS HD (SFF-8643) x 3, Slimline (SFF-8654) x 8
HDD Interface SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8

Rear Backplane Type-1 Mini-SAS HD & Slimline rear backplane
Dimension (W x H) 405mm x 72.3mm
Backplane Type Active with expander onboard
Host Interface Mini-SAS HD (SFF-8643) x 3, Slimline (SFF-8654) x 4
HDD Interface SAS/SATA x 12 or SAS/SATA x 8 and NVMe SSD x 4

Front Backplane Type-2 Mini-SAS HD & OCuLink front backplane
Dimension (W x H) 386 x 162mm
Backplane Type Active with expander onboard
Host Interface Mini-SAS HD (SFF-8643) x 3, OCuLink (SFF-8611) x 8
HDD Interface SAS/SATA x 24 or SAS/SATA x 16 and NVMe SSD x 8

Rear Backplane Type-2 Mini-SAS HD & OCuLink rear backplane
Dimension (W x H) 405mm x 72.3mm
Backplane Type Active with expander onboard
Host Interface Mini-SAS HD (SFF-8643) x 3, OCuLink (SFF-8611) x 4
HDD Interface SAS/SATA x 12 or SAS/SATA x 8 and NVMe SSD x 4
* InWin NVMe backplane supports PCIe 4.0, the actual data transfer speed will be determined by MB and HDD specifications.
* All components and optional parts are not included. In Win Development Inc. reserves the right to make any final modification.

Item Download Preview
IW-RS436-07 eDM
IW-RS436-07 Gallery -
IW-RS436-07 Compatibility List
IW-RS436-07 User Manual
IW-RS436-07 Front Slimline Backplane User Manual
IW-RS436-07 Front OCuLink Backplane User Manual
IW-RS436-07 Rear Slimline Backplane User Manual
IW-RS436-07 Rear OCuLink Backplane User Manual
Item Part Number Description Support Picture
Slide Rail 3RAMIS152700 28" tool-less & ball-bearing slide rails (weight capacity 60kg) 1 set
Cable 3RAMW4031700 Mini SAS 12Gbps SFF-8643 to SFF-8643 cable, 800mm Max.6
Cable InWin can customize the SFF-8611/ SFF-8654 cables to fulfill customers' OCuLink/Slimline connectors requirements. Max.12
Power Supply 3RAMAP026501 80 Plus Platinum CRPS 1200W (AC input 100-127V, total power 800W max. / AC input 200-240V, total power 1200W max.) Max. 2
Power Supply 3RAMAP039402 CRPS PDB 1
Backplane 2RBTVI009700 Mini-SAS HD & Slimline front backplane 1
Backplane 2RBTVI005500 Mini-SAS HD & OCuLink front backplane 1
Backplane 2RBTVI009500 Mini-SAS HD & Slimline rear backplane 1
Backplane 2RBTVI005300 Mini-SAS HD & OCuLink rear backplane 1
HDD Tray 2RAKPH057702 2.5"/3.5" hot-swap HDD tray (gray color) Max. 36
HDD Tray 2RAKPH038002 2.5" /3.5" hot-swap HDD tray (black color) Max. 36
HDD Tray 2RAKPH063701 2.5"/3.5" hot-swap HDD tray (gray color with NVMe symbol) Max. 12
HDD Tray 2RAKPH038102 2.5"/3.5" hot-swap HDD tray (black color with NVMe symbol) Max. 12
HDD Tray 2RAKPH057800 2.5" screwless hot-swap SSD rear tray (gray color) Max. 2
HDD Tray 2RAKPH038200 2.5" screwless hot-swap SSD rear tray (gold color) Max. 2
Fan 3RAMFB015400 80 x 38mm PWM hot-swap top fan, 8300RPM, 4pin Max. 4
Fan 2RAKFB010200 80 x 38mm PWM hot-swap top fan & fan bracket, 8300RPM, 4pin Max. 4
Fan 3RAMFB016301 80 x 38mm PWM hot-swap bottom fan, 12000RPM, 6pin Max. 4
Fan 2RAKFB011601 80 x 38mm PWM hot-swap bottom fan & fan bracket, 12000RPM, 6pin Max. 4
Other 2RAKIP023300 Mesh front panel 1
